360 Degree rotated mini crane with winch with clutch

360 Degree Portable Outdoor Small Crane for Construction Mini Davit Crane with Electric Wire Rope Hoist
1. This type can be rotated for 360 degrees which can solve the problems of the rope twisting and difficulty in rotation during the work.
2. The winching part changes the disadvantage of the short lifespan of the turbine reducer to make the electromagnetic braking motor much more powerful.
4. The electricity type is designed with the clutch device to win the fast speed when falling down to improve the efficiency.
5. The most important is that the rotation part is installed with the automatic positioning device which will be much more safe.
Quantity:
  • VOHOBOO

  • Mini Crane

  • Bearing, Gearbox, Motor, Gear

  • 500 kg

  • Chain Hoist

  • Manual

  • 200-1000kg

  • 180 ° 360°

  • 15m/min

  • 500kg 800kg 1000kg

  • 3M-5M

首图 p description1
主图

  1. Compact Size:

    • Mini cranes are characterized by their small and compact design. This allows them to access and operate in areas where larger cranes might face limitations.
  2. Maneuverability:

    • These cranes are highly maneuverable and can navigate through narrow spaces, making them suitable for construction sites, indoor projects, and other environments with spatial constraints.
  3. Lifting Capacity:

    • While mini cranes are smaller than traditional cranes, they still offer substantial lifting capacities. The lifting capacity can vary depending on the specific model, ranging from a few hundred kilograms to several tons.
  4. Telescopic Boom:

    • Mini cranes typically feature a telescopic boom that can extend or retract. This allows for flexible reach and height adjustments, making them adaptable to various lifting scenarios.
  5. Crawler Tracks:

    • Many mini cranes are mounted on crawler tracks, providing stability and allowing them to traverse uneven or rough terrain. The tracks also minimize ground pressure, reducing the impact on the working surface.
  6. Remote Control:

    • Some mini cranes come equipped with remote control systems, allowing operators to control the crane from a safe distance. This is particularly useful when working in tight spaces or hazardous environments.
  7. Outriggers:

    • To enhance stability during lifting operations, mini cranes may be equipped with outriggers that extend outward from the crane's base. Outriggers provide additional support and prevent tipping.
  8. Electric or Diesel Power:

    • Mini cranes can be powered by electric or diesel engines. Electric models are suitable for indoor use where emissions need to be minimized, while diesel models offer greater flexibility in outdoor environments.
  9. Hook and Safety Features:

    • Mini cranes come with a lifting hook for attaching loads. Additionally, they are equipped with safety features such as overload protection systems and emergency stop buttons to ensure safe operations.
  10. Versatility:

    • Mini cranes are versatile and can be used for a variety of lifting applications, including installing glass panels, HVAC units, steel beams, and other materials in construction and maintenance projects.
  11. Transportability:

    • The compact design and lightweight construction of mini cranes make them easily transportable. Some models can be disassembled for transportation and reassembled on-site.
  12. Applications:

    • Mini cranes are commonly used in construction projects, building maintenance, shipyards, and manufacturing facilities. They are ideal for tasks that require precision lifting in confined spaces.
product advantages

Product Details:

Outdoor cranes are also called small cranes, portable cranes, mini cranes, electric cranes, etc.
Structural features of outdoor crane:


This product is small in size, light in weight, compact and easy to operate. It uses 380V/220V voltage and is
suitable for decoration, lifting operations, installation equipment, moving companies, factories, workshops,
light industry, heavy industry, maintenance, warehouses, logistics, etc. The machine is composed of two parts:
power unit and bracket.

1. The power unit is composed of a motor, a reducer, a clutch, a brake, a rope drum and a steel wire rope.
The motor is a magnetic single-phase capacitor motor, which is designed with a mechanism that brakes
when the power is turned off; the motor is also equipped with a thermal switch, and the reducer is a two-stage
gear reduction, which is fixedly connected to the motor; the brake and the fly tube are installed as a whole,
which can be To achieve rapid decline.


2. The support part is composed of the main support rod and the cantilever boom. The rotating arm can rotate
360 degrees on the main pole, and a travel switch is provided at the end of the arm to prevent lifting accidents
caused by operating errors or button failure. Operate the button starter to realize the forward and reverse rotation
of the motor. The wire rope can be wound and released, and part of the bracket is hoisted by pulleys, and the
objects are lowered to complete the hoisting operation.
1 ton - Eng200kg - Eng

吊运机匹配电机
应用+优势
230404 1t mini crane with electric winch
2 sets 1T mini crane & KCD750-1500 to Congo1
photobank (1)
