Product Overview & Market Positioning

The VOHOBOO ER Series Electric Chain Hoist is a new-generation, heavy-duty industrial lifting system manufactured by Wuhan Vohoboo Import & Export Trade Co., Ltd.. Engineered to outperform conventional market hoists (such as the traditional HHBB series), the ER series integrates European-standard design, an ISO M5 / FEM 2m high duty rating, and comprehensive IP55 ingress protection.

With its compact headroom, whisper-quiet operation, modular maintenance architecture, and triple-security failsafe mechanism, the ER series delivers high duty cycles (up to 60% ED), maximum operating safety, and extended service life across demanding manufacturing, assembly, warehousing, and cleanroom environments.

1. Electric Motor:
* The hoist is powered by an electric motor, typically mounted on the hoist body or housing.
* The motor provides the necessary power to drive the lifting mechanism
2. Lifting Mechanism:
* The lifting mechanism consists of a chain or wire rope that is wound around a drum or sprocket.
* In the case of an electric chain hoist, a load chain is used. The chain is designed to handle heavy loads and is driven

by the electric motor.
3. Load Chain:
* The load chain is a durable chain made of high-strength materials, capable of withstanding the weight of the load

being lifted.
* It is attached to a lifting hook or other load attachment device.
4. Lifting Hook or Attachment:
* The lifting hook or attachment is the point where the load is connected to the hoist.
* It is designed to securely hold the load during lifting and lowering operations.
5. Control System:
* Electric chain hoists are typically equipped with a control system that allows operators to control the lifting

operations.
* Control options may include push-button pendant controls, radio remote controls, or in some cases, a control panel on

the hoist itself.
6. Safety Features:
* Electric chain hoists often come with various safety features, such as overload protection, emergency stop buttons,

and limit switches to prevent overtravel.
* Some hoists also have thermal protection to prevent the motor from overheating during prolonged use.
7. Mounting and Configuration:
* Electric chain hoists can be configured for different mounting options, including hook-mounted (for attachment to a

beam or trolley) or trolley-mounted (for horizontal movement along a beam).
* The hoist may be designed for single or dual speed operation, depending on the application requirements.
8. Capacity and Speed:
* Electric chain hoists come in various lifting capacities, ranging from a few hundred pounds to several tons.
* Lifting speed is another important specification, and hoists may have single or dual speed options.

Type	Capacity(Ton)	Lifting Height(m)	Lifting Speed(m/min)	Gourd	Sports Car
Type	Capacity(Ton)	Lifting Height(m)	Lifting Speed(m/min)	Gourd	Sports Car
ER01-01Y	1	4	7.0	47	38
ER02-01Y	2	4	7.0	91	44
ER02-02Y	2	4	3.5	54	44
ER03-01Y	3	4	7.0	104	55
ER03-02Y	3	4	3.5	108	55
ER05-02Y	5	4	3.5	132	77
ER075-03Y	7.5	4	2.3	175	77

Type	Capacity(Ton)	Lifting Height(m)	Lifting Speed(m/min)
ER10-04l	10	4	3.5
ER15-06l	15	4	2.3
ER20-08l	20	4	1.75
ER25-10l	25	4	1.4
ER30-12l	30	4	1.17

Type	Capacity(Ton)	Lifting Height(m)	Lifting Speed(m/min)
ER10-04Y	10	4	3.5
ER15-06Y	15	4	2.3
ER20-08Y	20	4	1.75
ER25-10Y	25	4	1.4
ER30-12Y	30	4	1.17

Triple Security & Failsafe Protection Mechanism

Safety is the fundamental pillar of VOHOBOO lifting equipment. The ER series comes standard with a three-layer failsafe system:

Heavy-Duty Electromagnetic Motor Brake:

High-temperature resistant electromagnetic brake mechanism.
Activates instantly upon power interruption, providing fail-safe mechanical locking with strong holding torque and minimal wear.

Mechanical Friction Clutch (Overload Prevention):

Independently developed built-in slip clutch.
Automatically slips if load exceeds rated capacity, protecting the hoist chassis, gear train, motor, and load chain from structural damage regardless of ambient temperature.

Dual Upper & Lower Travel Limit Switches:

Cuts off the motor control circuit immediately when the hook reaches top or bottom travel limits, preventing chain over-travel, drum jamming, or chassis impact.

Enhanced Operational Safety:

36V Low-Voltage Pendant Control: Eliminates electric shock risks for the operator; fitted with an ergonomic Emergency Stop button.
Drop-Forged 360° Swivel Hooks: Equipped with a heavy-duty safety latch and internal thrust bearing; deforms gradually under severe overload rather than sudden brittle fracture.
Precision Chain Guide: Special guide channel feeds the chain smoothly into the pocket wheel, preventing chain twisting and jamming.
