1t 1.5t 1.6m 2m 2.5m 3.0m Full Electric Pallet Stacker Motorized Battery Forklift

Electric Pallet Stacker features:
* The vehicle has a short length, high performance, and small ·channel requirements.
* Integrated module circuit control, easy to repair and replace parts.
* Offset control to enhance the field of view and reduce safety accidents.
* Lengthen the operating handle to reduce the power required for the entire vehicle operation, and operate lightly.
* 180 degree no dead angle steering, more flexible control.
Quantity:
  • VOHOBOO

  • Electric pallet stacker

  • Lifting Tools

  • Electric

  • 1.5-2t

  • 1650*800*2000mm

  • 550/680mm

  • 1100mm

  • 510 kg

  • Pressure vessel, Motor, Bearing, Gear

  • AC Motor

2
A full electric stacker, also known as a fully electric stacker or electric stacker forklift, is a type of material handling equipment designed for lifting, transporting, and stacking pallets and other loads. Unlike traditional forklifts that may use internal combustion engines, a full electric stacker relies entirely on electric power for its operation. Here's a more detailed description:

Electric Power: A full electric stacker is powered by an electric motor, which is usually supplied by a rechargeable battery. The electric power provides the energy needed for lifting, lowering, and horizontal movement.

Lifting Mechanism: The stacker is equipped with a lifting mechanism, typically a set of forks, that can be raised or lowered to lift and transport palletized loads. Some electric stackers may have a mast that allows for stacking at various heights.

C ontrols: Operators control the movements of the full electric stacker through a control panel or a set of ergonomic controls. These controls allow for precise and efficient handling of loads, including lifting, lowering, and steering.

Maneuverability: Electric stackers are known for their excellent maneuverability, especially in confined spaces. Their compact design enables them to navigate through narrow aisles and tight spaces, making them well-suited for warehouse and storage environments.

Load Capacity: Full electric stackers come in various load capacities, ranging from smaller units designed for light-duty applications to larger units capable of handling heavier loads. The load capacity is a critical consideration based on the specific needs of the application.

B attery Life: The battery life of the electric stacker depends on factors such as the size of the battery, the frequency of use, and the weight of the loads being handled. Many electric stackers are designed to operate for a full shift on a single battery charge, and some models may offer quick-charging capabilities.

Safety Features: Electric stackers are equipped with safety features to ensure safe operation. These features may include emergency stop buttons, horn signals, and sensors to detect obstacles. Some models may have stability features to prevent tipping during operation.

Compact Design: Electric stackers are designed with a compact and streamlined structure, allowing them to operate efficiently in confined spaces. This design feature is crucial for maximizing storage space in warehouses.

Quiet Operation: Compared to internal combustion forklifts, electric stackers operate quietly. This can be advantageous in noise-sensitive environments such as retail spaces or indoor warehouses.

Environmentally Friendly: The use of electric power makes full electric stackers more environmentally friendly compared to forklifts powered by internal combustion engines. They produce zero emissions during operation, contributing to a cleaner and healthier work environment.

Full electric stackers find applications in various industries, including logistics, manufacturing, retail, and distribution, where efficient and versatile material handling is essential. When selecting a full electric stacker, it's crucial to assess the specific requirements of your application and choose a model with the appropriate load capacity and features to meet your needs.

5
4
3
Drive type
/
Electric
Driving Style
/
Stand-and-drive type
Load Capacity
kg
1500
2000
Load centre
mm
500
wheelbase
mm
1383
tyre
/
Polyurethane wheels
Drive wheel size (diameter*width)
mm
φ210*70
φ250*80
Front wheel size (diameter*width)
mm
φ80*70
Balance wheel size(diameter*width)
mm
φ125*50
φ125*40
Front Wheelbase
mm
500
Rear wheelbase
mm
616
Overall height(Min height)
mm
2080/1580/1830/2080/2330
lift height
mm
1600/2000/2500/3000/3500
Min height
mm
≤90
Operating handle height above ground (max/min)
mm
1520/1050
Overall Length (stand up/down)
mm
2023/2419
2030/2419
Overall Width
mm
852
850
Fork size
mm
170/55/1150
Outer width of fork
mm
680
Min height
mm
30
Turning radius(Pedal up)
mm
1619
Travel speed (empty /no load)
km/h
4/5
Max. climbing ability(no load)
mm/s
100
Max. climbing ability(empty load)
mm/s
50
Max. climbing ability(empty /no load)
%
3/5
service brake
/
Electromagnetic brake
Drive motor rating
kw
DC0.75
DC1.5
Lifting motor rating
kw
DC2.2
Battery voltage/rated capacity
a/ah
2*12v/120ah
