Detailed explanation of the function of chain guide of electric chain hoist

Electric chain hoist is also called electric chain hoist. It is a kind of electric lifting equipment that is smaller and lighter than wire rope electric hoist. Electric chain hoist is widely used in factories, mines, workshops and other production sites. Electric chain hoist consists of many accessories, and the chain guide is one of them.

 What are the operations of the chain guide of the electric chain hoist? We all know that the chain of the electric hoist is located in the sprocket, and the meshing transmission is relatively jump and impact larger, so a device is needed to help the chain move regularly according to the shape of the sprocket. This is the function of the chain guide.

 At present, there are many types of electric chain hoists and guide chains, including a pressure wheel type and a pressure plate type. The pressure plate type is divided into a flat ring chain type and a pressure vertical ring chain type. The size of the chain guide should be determined according to the actual chain and sprocket gear. This is a technical parameter that requires process and test verification. The chain guide plays a role in protecting the smooth running of the chain. If the design of the chain guide is wrong, it will hinder the smooth running of the chain.

Each component of the electric chain hoist plays a very important role in the normal operation of the electric hoist, and the quality of each accessory directly affects the quality of the electric chain hoist.
