F24-6S/6D
VOHOBOO
Product Description:
F24 series remote control system have 80 channels in its frequency range. Even in situation where many sets of remote control are used in the same time,working channel can be easily chose without interfering with other signals and hundred-percent safe and reliable. With advanced design and high quality components, the system is durable and easy to operate. It can easily adapt to complicated and harsh industrial environments such as extra-high/low temperature, dusty, strong vibration, greasy, heavy humidity, etc.
Transmitter and receiver have many functions used in conjunction. The emergency stop button is located in the upper left of transmitter which meets the safety and ergonomics. When stop button is pressed, the system stop working immediately and unconditionally. Transmitter is equipped with a shell of more consistent with ergonomics. The new shell material is more durable,lighter and thinner.
There are 30 types of different configurations based on customer’s requirements.Maximum 20 control contacts are sufficient to meet most of requirements. The technique, function, security and flexibility satisfy all your requirements. It is the most advanced remote control system.
Features:
1. 7-12 buttons (D means double steps), STOP, START, spare buttons
2. Up to 20 control contacts
3. With battery voltage warning device, the power supply is cut off during low power
4. Safety switch key is to prevent from unauthorized user
5. Program the button function by computer interface
6. Up/down, east/west, south/north can be programmed to interlock or non-interlock
7. Power key can be programmed to start, toggle switch, normal or other functions
8. The spare buttons can be programmed to normal, interlock, toggle or start, etc
Product Parameter:
| Transmitter Parameters: F24. -TX | |
| Material | Glass-Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331 MHz; UHF: 425~446MHz |
| Transmitter power | ≤10dBm |
| Transmitter power supply | 2 AA batteries |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
| Control distance | Approx 100m (200 meters is customized) |
| Receiver Parameters: F24-RXC | |
| Material | Glass -Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331MHz; UHF: 425~446MHz |
| Receiver sensitivity | -110dBm |
| Receiver power supply | 18~65V AC/DC / 65~440V AC/DC ( optional ) |
| Output contactor capacity | 8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
| Control distance | Approx 100m (200 meters is customized) |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
Application:
The heavy industrial machinery, such as lifting machinery, crane,hydraulic crane, concrete pump, roller coaster, mining machinery, hoist,truck crane, dump truck, lifting locomotive, lifting machine etc.
Product Description:
F24 series remote control system have 80 channels in its frequency range. Even in situation where many sets of remote control are used in the same time,working channel can be easily chose without interfering with other signals and hundred-percent safe and reliable. With advanced design and high quality components, the system is durable and easy to operate. It can easily adapt to complicated and harsh industrial environments such as extra-high/low temperature, dusty, strong vibration, greasy, heavy humidity, etc.
Transmitter and receiver have many functions used in conjunction. The emergency stop button is located in the upper left of transmitter which meets the safety and ergonomics. When stop button is pressed, the system stop working immediately and unconditionally. Transmitter is equipped with a shell of more consistent with ergonomics. The new shell material is more durable,lighter and thinner.
There are 30 types of different configurations based on customer’s requirements.Maximum 20 control contacts are sufficient to meet most of requirements. The technique, function, security and flexibility satisfy all your requirements. It is the most advanced remote control system.
Features:
1. 7-12 buttons (D means double steps), STOP, START, spare buttons
2. Up to 20 control contacts
3. With battery voltage warning device, the power supply is cut off during low power
4. Safety switch key is to prevent from unauthorized user
5. Program the button function by computer interface
6. Up/down, east/west, south/north can be programmed to interlock or non-interlock
7. Power key can be programmed to start, toggle switch, normal or other functions
8. The spare buttons can be programmed to normal, interlock, toggle or start, etc
Product Parameter:
| Transmitter Parameters: F24. -TX | |
| Material | Glass-Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331 MHz; UHF: 425~446MHz |
| Transmitter power | ≤10dBm |
| Transmitter power supply | 2 AA batteries |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
| Control distance | Approx 100m (200 meters is customized) |
| Receiver Parameters: F24-RXC | |
| Material | Glass -Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331MHz; UHF: 425~446MHz |
| Receiver sensitivity | -110dBm |
| Receiver power supply | 18~65V AC/DC / 65~440V AC/DC ( optional ) |
| Output contactor capacity | 8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
| Control distance | Approx 100m (200 meters is customized) |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
Application:
The heavy industrial machinery, such as lifting machinery, crane,hydraulic crane, concrete pump, roller coaster, mining machinery, hoist,truck crane, dump truck, lifting locomotive, lifting machine etc.
